1.140 horsepower, while its ultra-low fuel consumption of less than 248g/kwh, and an ultra-large torque output of 88-124n.m, make your work more efficient , More energy-saving; standard cold start preheating device, can quickly start in cold winter.
2.The new second/third generation sunshade and detachable cab greatly save shipping space and reduce transportation costs. At the same time, it adopts an ergonomic arc-shaped design concept and provides heating and other configurations to provide you with a larger, safer and more comfortable Driving environment.
3.Single and double-acting clutches are available to meet different needs and operations. The friction plate is made of special ceramic material, which can provide you with more convenient operation and reliable performance.
4.For rainy and humid places, we provide a waterproof electrical system configuration, high-sealing electrical wiring and connectors to ensure the service life of the electrical system and let you work worry-free.
5.We adopt the domestic advanced lifting system, which can be adjusted individually, and the maximum lifting force at the suspension point can reach 5.78 kN, making your work more efficient.
6.We use a new type of power combination instrument, which has the advantages of high sealing and multi-information integrated display, so that you can accurately understand all the information at any time.
Imported material powder, metallurgical processing technology. The friction plate is more wear-resistant and has a longer life!
The "Fiat" partition wall has good rigidity, high strength and low noise. The material is upgraded to HT250 (gray cast iron)
The new integral fully sealed front axle, the front axle adopts double-cylinder steering front axle, the steering is easier, more flexible and the left and right steering are consistent!
|Model||BIA 120 BIA 130|
|Type||Latest safe cabin , Optional: Fan or Heater or A/C|
|Type||6-cylinder, in-line, water cooled, four-stroke|
|Bore x stroke||mm||ø105×130|
|Steering, Brake system|
|Brake type||Wet, Disc and Hydraulic|
|Transmission box||4x(2+1) x2 combined type|
|Shift gear mode||Engagement sleeve|
|Frame type||New enhanced frameless|
|Tire (Front/Rear)||7.50-20/16.9-34 (2WD)/13.6-24/16.9-34 (4WD)|
Option: Paddy-field tire
|Tire pressure||kPa||230-210/160 (2WD)/ 230-210/180 (4WD)|
|Suspension system mode||Split type|
|Suspension device type||Post-position three point suspension|
|Category of suspension system||II category|
|Adjusting way||Force and position|
|Hydraulic output device||Double-way valve|
|Safety valve open pressure||Mpa||17.5-18|
|PTO shaft type||Post-position, Independent|
|PTO shaft spline||6/8|
|PTO shaft spline diameter||ø35/ ø38|
|PTO shaft rev.||760/850, Optional: 540/1000|
Bulk order we will using Iron box to packing, before packing will disasemble the tyres,ROPS,silencer and so on, Let the container can loading more. If only one or three tractor will be loading in whole body, becuase if disassemble it the client will be hardly to assembly it, influence the working efficiency.
1.Top Quality Services
2.End to End Services
3. After-sales Service
1. Fast technical guidance for construction, installation and commissioning.
2. Necessary training for daily maintenance on site.
3. 18 months warranty.
4. Lifelong regular technical service.
5. Timely solutions to problems.
Do the best Quality, Do the best Service!
